Automatic Milk Tablet Counting Filling Packaging Machine / Pill Packaging Machine

This automatic counting packing machine, is suitable for milk tablet packaging, pill and tablet packaging,. It completes tablet piece counting, filling, bagging with high precision.

Product Parameters

BrandEASYREALM
NO.YLM-260V1-CP
Get Latest Price

Machine Introduction

Automatic Milk Tablet Counting Filling Packaging Machine / Pill Packaging Machine

  • Infrared optical counting system; high precision of counting.
  • Applicable for many products; very ecosnomic.
  • Vibratory feeder, easy to change.
  • For different bag size, only need to set the data on the touch screen.
  • Set the required number of parts packed and package number on the 7-inch color touch screen, the machine can do packaging accurately.
  • PLC control system is easy to use, stable and durable.
  • Minimal maintenance requirements
  • Intelligent temperature controller
  • The machine stops automatically while vibratory feeder lacking in material
  • Counting, bag forming, filling, sealing and cutting is done in one time.


Machine Video


Machine Applications

  • Take-away conveyor
  • Highly sensitive checkweighers
  • Sponge soundproof housing
  • Automatic labeler
  • Gas(Nitrogen) flush device
  • Tear notch device
  • Round or Euro hole punch device
  • Alarm light
  • Automated feeding system
  • Code printer


Pouch Types

milk tablets, pills, capsule, jelly beans, bubble gum, etc.


Machine Specifications

ModelYLM-260V1-CP
FilmOPP/CPP,OPP/PE,CPP/PE
Bag Lengthmax. 280mm(bag pulling twice)
Bag Width70-150mm (forming device needs changing for different size)
Film Widthmax. 320 mm
Packing Speed20-60 bag/min (according to characristics of parts packed, film, number of parts per bag
Counting MethodInfrared optical counting system / track positioning
Quantity of Parts per BagAs long as the bag can accomodate
Bag Typepillow pack or three side sealed
Seam Width10 mm


Bag Forming Devicetrunk forming device, pneumatic sealing and cutting
Cutting Methodpattern welded knife
Bag Length Controlsetting on touch screen / photoelectric sensor
Air Discharging Methodair hole
Linking Bagfunction of bag linking can be set on touch screen
Air pressure0.4-0.8Mpa (air compressor prepared by customer)
Voltage220V 50Hz or customized
Power2.0 Kw
Overall SizeCustomized
